基于PLC的智能交通系统的设计

基于PLC的智能交通系统的设计(论文12000字)
摘要:本文主要以现阶段的十字路口交通灯为依据设计出一种以PLC为控制单元根据车流量的差异来改变交通灯时间的一套十字路口交通灯系统。PLC可控编程器具有结构紧凑、可靠性高、环境适应性强、使用方便灵活的特性。同时，PLC内部的定时器资源丰富，可以方便快捷精确的对各类交通信号灯进行精确有效的控制，现阶段其在交通灯系统中得到普遍的推广使用。
关键词：可控制编程器；定时器；特性；

Design intelligenttransportation system based on PLC
Abstract:In this paper,this system is a PLC of control the unit based on the difference traffic traffic light.It can changetraffic light time on the basis of traffic volume.This system is based on the traffic lights .PLC control programmerhas the characteristics of compact structure, high reliability and environmental adaptability, convenient and flexible .At the same time, the PLC internal timer is rich in resources.It can work in all kinds of traffic lights for precise control.At this stage, it is widely used in the traffic light system. [资料来源：www.THINK58.com]
Key words: control programming; timer; characteristics;
