室内温度监控远传系统设计(论文14000字)
摘要:随着人们对生活品质追求的提升,冬季供暖问题,尤其在北方集中供暖地区愈发突出。为解决用户室内温度是否达到规定的温度范围的争议,设计了一款室内温度监控远传系统。该系统以MSP430单片机为主控芯片,DS18B20温度传感器对现场的温度进行实时监测,经由GSM模块与上位机无线通讯,方便随时查看室内温度状况,实现温度的监控远传。该系统具有功耗低、便携性强、存储量大、实时监控等特点。
关键词:MSP430;DS18B20;GSM模块
Design and implement of remote transmission system for indoor temperature monitoring
Abstract:With the improvement of people's pursuit of quality of life, the heating problem in winter, especially in central heating areain the north, is becoming more and more prominent. An indoor temperature monitoring system is designed to solve the dispute of whether the indoor temperature reaches the specified temperature range. The system is controlled by MSP430 MCU,which is treated as master chip.DS18B20 temperature sensor is used to monitor the temperature of the site in real time and wireless communication with the host computer is realized byGSM module, achieving the goal of the remote control of temperature. The system has the characteristics of low power consumption, strong portability, large storage capacity and real-time monitoring. [来源:http://think58.com]
Key words:MSP430;DS18B20;GSM module
[来源:http://think58.com]
