基于STM32的电压采集系统的设计

基于STM32的电压采集系统的设计(任务书,开题报告,外文翻译,论文13000字,答辩记录)
摘   要
本课题基于STM32开发板，设计了一款能够采集-3V~3V直流电压的电压采集系统。由于STM32开发板的A/D模块只能采集正电压，所以本课题需要设计一个电路可以使输入信号转变为STM32能够采集的电压，该电路即为信号调理电路。文中第一章首先是对电压采集系统的历史背景和设计意义和现状进行了分析，第二章则是对基于STM32的电压采集系统进行需求分析以及问题的解决方案。第三章则对硬件部分的具体实现过程进行了说明，列出不同的方案并加以分析，进行对比选出最合适的电路。在理解了采集系统的功能要求和芯片使用方法后，设计了软件流程，分析了主要的程序段。接下来是软件和硬件联合调试，描述了实际调试中遇到的问题，并分析原因。本文的结尾对该系统进行了误差的分析和改进。
关键词：电压采集系统  信号调理电路 STM32

The voltage acquisition system based on STM32
Abstract
On the basis of STM32 development board, this research designs a voltage acquisition system which can acquires -3V~3V direct voltage. Since the A/D module of STM32 development board can only acquire positive voltage, this research needs to design a circuit which can convert the input signal into the voltage that can be acquired by STM32. This circuit is signal conditioning circuit. The first chapter analyzes the historical background, significances and current situation of voltage acquisition system; the second chapter is the requirements analysis and the solutions to the problems based on voltage acquisition system; the third chapter explains the concrete realization process of its hardware, lists and analyzes various schemes, and selects the most proper circuit after comparison. After understanding the function requirements of acquisition system and the usage of chip, the writer designs the software process and analyzes the main program segment. And next is to debug both the software and hardware, describes the problems in the practical debugging and analyzes their reasons. The last part of the paper analyzes the errors and improves this system.

Key Words : Voltage acquisition system; Signal conditioning circuit; STM32
