基于STM32的蓝牙无线温度采集系统设计

基于STM32的蓝牙无线温度采集系统设计(论文16500字)
摘要：随着物联网的发展和智能手机的普及，传感器连接互联网成了大趋势。传统的温度采集是采用现场总线的方式连接多个温度结点，控制温度主要依靠人操作机械开关。其缺点显而易见，读取温度只能在统一的监控室内，而且线路的铺设成本高，温度结点出故障时需要拆除线路检修，温度控制对人力成本要求高，可能存在误操作等很大的安全隐患。鉴于此，本设计采用高性能的STM32嵌入式处理器，连接数字式温度传感器，采用蓝牙无线的方式传出温度值并且接收控制命令。温度采集可以在非接触式的方式下进行，可以通过智能手机读取温度数据。整个系统采用嵌入式系统，模拟电路较少，提高系统的稳定性。并且蓝牙传输方式应用范围广，接收端形式多样。
关键字: STM32；物联网；嵌入式；蓝牙通讯

Design of temperature acquisition system based on STM32 embedded processor and bluetooth technology
Abstract: With the development of the Internet of things and the popularity of smart phones, sensors connected to the Internet has become a major trend. The traditional temperature acquisition is the way of using the field bus to connect more than one temperature node, the control temperature mainly rely on people to operate the mechanical switch. Its shortcomings are obvious, read the temperature only in a unified monitoring indoor and line of the high cost of laying, the junction temperature failure to dismantle line maintenance, temperature control of high demand for labor costs may misuse and great security risks exist. In view of this, this design uses the high performance STM32 embedded processor, connect the digital temperature sensor, using Bluetooth wireless way to spread the temperature value and receive the control command. Temperature acquisition can be carried out in a non-contact manner, the temperature data can be read through the smart phone. The whole system adopts embedded system, the analog circuit is less, and the stability of the system is improved. And Bluetooth transmission mode has a wide application range, and the receiving end is diverse.

Keywords:  STM32; Internet of things; embedded; Bluetooth communication
