双频双极化天线设计

以下是资料介绍,如需要完整的请充值下载.
1.无需注册登录,支付后按照提示操作即可获取该资料.
2.资料以网页介绍的为准,下载后不会有水印.资料仅供学习参考之用.

资料介绍:

双频双极化天线设计(论文11000字)
摘要:本文提出了一种紧凑型双频双极化环槽平面天线。较低频带中的环路基本模式和较高频带中的槽基本模式用于实现双频带性能。两端口隔离在较低频段内端口隔离优于29 dB。 在较高频段,端口隔离在此频段优于28 dB。所提出的天线具有外形小巧、尺寸紧凑、良好的双频双极化特性、良好的端口隔离、稳定的辐射图和增益以及低交叉极化的优点。良好的性能使其成为实际WLAN/WiMAX应用的理想选择。
关键词:双频,双极化,环形天线,缝隙天线。

DeSign of a dual-frequency dual-polarized antenna
Abstract:In this paper, a compact dual-band dual-polarized loop-slot planar antenna is proposed. The Loop basic mode in the lower frequency band and the Slot Base mode in the higher frequency band are used to realize the dual-band performance. The isolation between two ports in the lower frequency band is better than 29dB. In higher frequency bands, port isolation is better than 28dB in this band. The proposed antennas have the advantages of small shape, compact size, good dual-frequency dual-polarization characteristics, good port isolation, Stable radiation graph and gain, and low cross polarization. Good performance makes it an ideal choice for practical WLAN/WiMAX applications. [资料来源:http://think58.com]
Key words:dual-band, dual-polarization, loop antenna, slot antenna.
