一种用于方向图分集的紧凑型双模超材料环形天线

一种用于方向图分集的紧凑型双模超材料环形天线(论文13000字)
摘要：本文提出了一种用于方向图分集的双端口双模超材料环形天线的设计方案。这种超材料的环形天线是由一个周期加载的电容式圆弧条和两个具有馈电网络的独立端口组成，此圆弧条由六块相同的圆弧组成，圆弧之间形成交指型缝隙。与mzr天线相似，本文提出的周期加载电容环天线允许沿环路的电流保持相同的相位和均匀性。利用混合馈电网络，超材料环形天线的奇偶模式有效地实现了天线的方向图分集。利用零阶共振理论，对构成环形天线的几个弧形条进行了新的设计，以获得水平极化全方位辐射模式。通过全波仿真和实验验证了该天线的工作原理和性能。
关键词：奇偶模，环形天线，方向图分集，可重构方向天线。

A Compact Dual-ModeMetamaterial-Based Loop Antenna for Pattern Diversity
Abstract：This letter presents a novel design of compact dual-port dual-mode metamaterial-based loop antenna for pattern diversity. The proposed metamaterial- based loop antenna consists of a loop based on periodically loaded capacitive arcstrips and two independent ports with feeding networks. This circular arc bar consists of six identical arcs, forming an intersect gap between the arcs.Similar to mu-zero resonance (MZR) antennas, the periodically loaded capacitive loop antenna proposed in this letter allows current along the loop to re-main in phase and uniform. By making use of a hybrid feed net-work, the even and odd modes of the proposed metamaterial-based loop antenna are exploited so that its pattern diversity is achieved effectively. using the theory of zeroth-order resonance, we have provided a novel design for several arc-shaped strips that make up the loop antenna to obtain the horizontally polarized omnidirectional radiation pattern.The theory of operation and performances of the pro-posed antenna are demonstrated in both a full-wave simulation and in the experiments.

Index Terms：Even mode and odd mode, loop antenna, , patterndiversity, reconfigurable pattern antenna
