电力系统谐波检测算法分析

电力系统谐波检测算法分析(论文14000字)
摘要：本篇论文，旨在针对电力系统谐波所涉及的算法检测过程，进行相对深入的细致研究。其中，本文着重于针对以三相瞬时无功功率理论为基础，而构建出的谐波电流检测算法，进行科学合理的综合探究，并深入阐述基于该理论的p-q、i_p-i_q、d-q这三种算法的原理，并在Matlab平台上构建相应仿真系统，验证三种算法的可行性，并对比三种算法的优劣，同时通过借助PI调节器以及更改LPF截止频率的两种方式，优化改进算法，进一步增加谐波检测的精准度。实验结果表明，通过这两种方式改进后，算法在谐波检测精度上较改进之前有较大提高。
关键词：谐波检测； 瞬时无功功率； p-q；i_p-i_q； d-q；
 
Analysis of Harmonic Detection Algorithms in Power System
Abstract：This paper aims to conduct a relatively in-depth and detailed study on the algorithm detection process involved in power system harmonics. Among them, this paper focuses on the harmonic current detection algorithm based on the three-phase instantaneous reactive power theory, and conducts scientific and reasonable comprehensive exploration, and elaborates on p-q, i_p-i_q, d-q based on the theory. The principle of the algorithm, and build the corresponding simulation system on Matlab platform, verify the feasibility of the three algorithms, and compare the advantages and disadvantages of the three algorithms. At the same time, optimize and improve by means of PI regulator and changing the LPF cutoff frequency. The algorithm further increases the accuracy of harmonic detection. The experimental results show that after the improvement of these two methods, the algorithm has a great improvement before the harmonic detection accuracy is improved. [版权所有：http://think58.com]
Key words：Harmonic Detection；Instantaneous reactive power；p-q；i_p-i_q； d-q；
